1oz Copper Thickness PCBA Board Manufacturer HDI medical equipment PCBA Multilayer Circuit PCBA
|
Layers |
1-32layers |
|
Materials |
CEM1,CEM3,Teflon,Rogers,FR-4,High Tg FR-4,Aluminum Base,Halogen Free |
|
Max. Board Size |
510*1200mm |
|
Material |
RoHS Directive-compliant |
|
PCB thickness |
1.6 ±0.1mm |
|
Out Layer Copper Thickness |
1-6oz |
|
Inner Layer Copper Thickness |
1/2oz-5oz |
|
Max. board Thickness |
6.0mm |
|
Minimum hole size |
0.20mm |
|
Minimum line width/space |
3/3mil |
|
Min. S/M Pitch |
0.1mm(4mil) |
|
Plate thickness and aperture ratio |
30: 1 |
|
Minimum hole copper |
20µm |
|
Hole dia. Tolerance(PTH) |
±0.075mm(3mil) |
|
Hole dia. Tolerance(NPTH) |
±0.05mm (2mil) |
|
Hole position deviation |
±0.05mm (2mil) |
|
Outline tolerance |
±0.05mm (2mil) |
|
Surface finished |
HASL Leadfree,Immersion ENIG,Chem Tin,Flash Gold,OSP,Gold finger,Peelable,Immersion Silver |
|
Solder mask |
green |
|
Legend |
white |
|
Outline |
rout and score/V-cut |
|
E-test |
100% |
|
Inspection standard |
IPC-A-600H/IPC-6012B, Class 2 |
|
Outgoing reports |
final inspection, E-test, solderability test, micro section and more |
|
Certificates |
UL (E315391), ISO 14001, TS16949, ISO 9001, SGS |
- Electronic components material purchasing.
- Bare PCB fabrication.
- PCB Assembly Service. (SMT, BGA, DIP).
- FULL Test: AOI, In-Circuit Test (ICT), Functioal Test (FCT).
- Cable, Wire-harness assembly,sheet metal,Electrical cabinet Assembly service.
- Conformal coating service.
- Prototyping and mass production...
- PCB layout, PCBA design according to your idea.
- PCBA copy/clone.
- Digital Circuit Design / Analog Circuit Design/ lRF Design /Embedded Software Design.
- Firmware and Microcode Programming Windows Application (GUI). Programming/Windows Device Driver (WDM) Programming.
- Embedded User Interface Design / lSystem Hardware Design...
- - Asia
- - Australasia
- - Central/South America
- - Eastern Europe
- - Mid East/Africa
- - North America
- - Western Europe
A: PCB : Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...).
PCBA: PCB information, BOM, (Testing documents...).
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF, word, txt).
A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.
A: There is no MOQ. We are able to handle Small as well as large volume production with flexibility.
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
A: Yes, we can provide component source, and we also accept component from client.
