FPGA PG2L100H PCIE optical fiber

Short Description:

Memory: 2 pieces 512MB total 1GB, 32bit, for data cache

QSPIFLASH: 2 pieces of 256mbitOSPIFLASH, used as FPGA configuration files and user data storage

Crystal: 1 50MHz with source crystal, providing a reference input clock for FPGA

Send email to us

Product Detail

Product Tags

Overview

Memory: 2 pieces 512MB total 1GB, 32bit, for data cache
QSPIFLASH: 2 pieces of 256mbitOSPIFLASH, used as FPGA configuration files and user data storage
Crystal: 1 50MHz with source crystal, providing a reference input clock for FPGA
2 125MHz active crystal, providing reference input clock with a reference input clock with a reference input clock with a reference input clock with the internal HSSTLP, the system clock source provided for the development board
HDMI input: 1 HDMI output, support 1080p@60Hz input, support data in different formats
HDMI output: 1 HDMI output, support 1080p@60Hz output, support 3D output
PCLEX2 interface: 1 road supports PCIEXPRESS2.0 standard high -speed data transmission interface
Optical fiber interface: 2 SFP high -speed fiber interface, communication receiving and sending speed is as high as 6.6GB/s
Gigabit Ethernet: 1 Road 10/100M/1000M Ethernet RJ-45 interface, providing network communication services
USB to Circile Put: 1 UART to USB interface for communication with computer, which is convenient for users to debug
EEPROM: EEPROM 24LC04 of 1 IIC interface
JTAG port: 10 stitches 2.54mm standard JTAG port, for downloading and debugging of FPGA programs
SD card seat: 1 Micro SD card seat, supports SP mode
LED: 5 users luminous secondary tube LED (1 on the core board, 4 on the expansion board)
Key: 4 user keys, 1 reset button
40 -pin expansion port: reserved 2 40 -pin 2.54mm extensions, which can be connected to various modules of black gold (double eyes
Camera, TFTLCD screen, high -speed AD module, etc.). Extended port contains 5V power 1 road,
3.3V Power 2 Road, Earth 3 Road, 10 ports and 34 roads

Power parameter

Input voltage +12V voltage Input power supply 12V/3A power supply
The maximum current input current 3A
