Weight Loss Control Weight Electronic Scale Circuit Board Can Be Customized Pcba
| Size Max. Board Size | 580mm×1100mm |
| Min. Drilled Hole Size | 0.2 mm (8 mil) |
| Min. Line Width | 4mil (0.1mm) |
| Min. Line Spacing | 4mil (0.1mm) |
| Surface finishing | HASL / HASL lead free, HAL, Chemical tin, Immersion Silver/Gold, OSP, Gold plating |
| Solder Mask Color | Green/Yellow/Black/White/Red/Blue |
| Tolerance Shape tolerance | ±0.13 |
| Hole tolerance | PTH:±0.076 NPTH/ ±0.05 |
| Certificate | UL, ISO 9001, ISO 14001 |
| Special requirements Buried and blind vias+controlled impedance +BGA | |
| Profiling Punching, Routing, V-CUT, Beveling |
| FOB Port | Shenzhen |
| Weight per Unit | 1.0 Kilograms |
| HTS Code | 8534.00.90 00 |
| Export Carton Dimensions L/W/H | 32 x 23 x 23 Centimeters |
| Lead Time | 3–15 days |
| Dimensions per Unit | 15.0 x 15.0 x 5.0 Centimeters |
| Units per Export Carton | 1000.0 |
| Export Carton Weight | 18 Kilograms |
To give you an exact quote,we hope you could offer us listed information.
1. PCB : Gerber file and other PCB files. We would appreciate if you can confirm PCB specification like material ,board thickness , copper thickness ,surface finishing , solder mask color , silkscreen color...
2. PCBA : PCB files and BOM list
3. If you don't have full design files, you can send us a sample, then we will clone for you.
4. We also offer custom PCB design and modify service.
- 1. Comprehensive documents audit to prevent mistakes in PCB Gerber and Bom.
- 2. Suggest best quality replacement with lower price.
- 3. Engineering support for test and provide suggestions for mass production.
- 4. Suggest best shipment method.
- 5. Sign NDA to keep your design safe.
- -If you need us to do function test, please also provide test instruction.
- - Asia
- - Australasia
- - Central/South America
- - Eastern Europe
- - Mid East/Africa
- - North America
- - Western Europe
-Industrial commander, and other industrial devices.
-Medical equipment main board.
-Security electronics
-Communicative devices
-New energy electronics
XinDaChang is a manufacturer with PCB factory and assembly factory.
Yes, we have 4 engineers specialized in testing, loading firmware, analyze failure...
North America, South America, West Europe and Australia.
-T/T, West Union,Money gram, L/C, D/P, D/A is acceptable, samples accept paypal.
-FOB, CIF, DDU, Ex-work.
-We need pcb layout file Gerber and Bom list to quote the PCBa cost.
-If you need us to do function test, please also provide test instruction.
1- lay PCB delivery time 5-10pcs need about 1-3days.
2- layer PCB delivery time need about 1-3days.
3- Multilayer PCB need about 4-7days.
-
