Wildfire LubanCat 2 developed board card computer image processing RK3568

Short Description:

  1. Luban Cat 2 is a high-performance single-board computer and embedded motherboard for display, control, network transmission, file storage, edge computing and other scenarios.
  2. Rockchip RK3568 as the main chip, the use of 22nm production process, the main frequency up to 1.8GHz, integrated quad-core 64-bit vertical Cortex-A55 processor and Mali G52 2EE graphics processor, support 4K decoding and 1080P encoding, support dual frequency display, built-in independent NPU, Can be used for lightweight AI applications.
  3. Provides multiple memory and storage combinations, balanced on-board hardware configuration, and wide application range.
  4. Built-in independent NPU computing power up to 1TOPS can be used for lightweight AI applications.
  5. High integration, has a rich expansion interface, with dual dry megabit network port, HDMI, USB3.0, MINI5PCI-E, M.2 interface, MIPI and other peripherals, to further expand the use of the board scene, small body can also send out great performance.
  6. Official support for mainstream Android 11, Debain, Ubuntu operating system images, can be applied to a variety of different application environments.

Product Detail

Product Tags

Board name LubanCat2
Power interface DC interface 5V@3A DC input or Type-C interface 5V@3A DC input
Master chip RK3568(quad-core Cortex-A55,2GHz, Mali-G52)
Internal memory 1/2/4/8GB LPDDR4/LPDDR4X 1560MHz
Store 8/32/64/128GB eMMC
Ethernet 10/100/1000M Adaptive Ethernet port x2
USB2.0 Type-A Indicates interface x1(HOST).Type-C interface x1(OTG) is a firmware burning interface shared with the power interface
USB3.0 Type-A Interface x1(HOST)
Debug serial port The default parameter is 1500000-8-N-1
Key ON/OFF(switch on/off), MaskRom(burn) key, Recovery key
Audio interface Headphone output + microphone input 2-in-1 interface
SPK horn port Can be connected to 1W power horn
40Pin interface Compatible with Raspberry PI 40Pin interface, support PWM,GPIO,I²C,SPI,UART functions
M.2 Port M Key, PCIE3.0x2Lanes, can plug 2280 NVME SSD
Mini PCle interface It can be used with full-height or half-height WIFI network cards, 4G modules or other Mini-PCle interface modules
SATA interface The SATA cable port is used with a conversion board and supports 5V power supply SATA ports
SIM card holder It needs to be used with a 4G module
HDMI2.0 interface Display interface, support with MIPI-DSI dual screen display, the highest resolution 4096*2160@60Hz
MIPI-DS interface MIPI screen interface, can plug the wildfire MIPI screen, support and HDMI2.0 dual screen display, the highest resolution 2560*1600060Hz
MIPI-CSI interface Camera interface, can plug the Wildfire OV5648 camera
TF card holder Support Micro SD (TF) card boot system, up to 128GB
Infrared receiver Supports infrared remote control
RTC battery port Supports the RTC function
Fan interface Supports fan heat dissipation

Chinese PCB manufacturers

PCBA manufacturer in China

Model name

Luban cat 0 network port version

Luban Cat 0
Wireless version

Luban Cat 1

Luban Cat 1
Online edition

Luban Cat 2

Luban Cat 2
Online edition

Master control

RK35664 coreA55,1.8GHz,1TOPS NPU

RK3568
4CoreA55,
1.8GHz
1TOPS NPU

RK3568B2
4CoreA55,
2.0GHz
1TOPS NPU

Store
eMMC

  None eMMC
Use SD card for storage

8/32/64/128GB

Internal memory

1/2/4/8GB

Ethernet

Giga*1

/

Giga*1

Giga*2

2.5G*2
giga*2

WiFi/Bluetooth

/

Onboard

Available via PCle
External module

Onboard

External modules can be connected via PCle

USB port

Type-C*2

Type-C*1,USB Host2.0*1,USB Host3.0*1

HDMI port

mini HDMI

HDMI

Dimension

69.6×35mm

85×56mm

111×71mm

126×75mm

Aerospace control systems

Instrument control system

Model name

Luban Cat 0
Net interface version

Luban Cat 0
Wireless version

Luban Cat 1

Luban Cat 1
Online edition

Luban Cat 2

Luban Cat 2
Online edition

MIPI DSI
Display interface
(4Lane)

MIPI CSI
Camera interface
(4Lane)

40pin GPIO
Pin arrangement interface

Audio output

X

×

Infrared receiver

×

X

PCle interface
(Can be connected to external WiFi
4G modules)

X

×

X

M.2 Ports
(Can be connected externally
SSD hard drive)

X

×

X

×

×

SATA
Hard disk interface

×

×

X

×

Available via FPC
Interface expansion

Smart meter control system
